Description
Dahua HD Camera HAC-HDW-1200R Features
Dahua HD Camera HAC-HDW-1200R 2MP IR Mini-Bullet HD Camera
2Megapixel CMOS 25/30fps@1080P High speed, long distance real-time transmission Day/Night(ICR), AWB, AGC, BLC, 2D-DNR 3.6mm fixed lens Max. IR LEDs length 15m, Smart IR IP67, DC12V
Dahua HD Camera HAC-HDW-1200R Specifications
| Camera HAC-HDW-1200R | |
| Image Sensor | 1/2.7″ CMOS |
| Effective Pixels | 1080, 2MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/25~1/100000sNTSC: 1/30~1/100000s |
| Minimum Illumination | 0.05Lux/F2.0, 0Lux IR on |
| S/N Ratio | More than 65dB |
| IR Distance | Up to 20m (66feet) |
| IR On/Off Control | Auto / Manual |
| IR LEDs | 12 |
| Lens | |
| Lens Type | Fixed lens / Fixed iris |
| Mount Type | Board-in |
| Focal Length | 3.6mm (2.8mm Optional) |
| Max Aperture | F2.0 |
| Angle of View | H: 60° (83.4°) |
| Focus Control | N/A |
| Close Focus Distance | 600mm (500mm)23.6 (19.69) |
| Pan / Tilt / Rotation | |
| Pan/Tilt/Rotation | Pan: 0° ~ 360°Tilt: 0° ~ 90° Rotation: 0° ~ 360° |
| Video | |
| Resolution | 1080P |
| Frame Rate | 25/30fps@1080P |
| Video Output | 1-channel BNC HDCVI high definition video output / CVBS video output (Can switch) |
| Day/Night | Auto (ICR) / Manual |
| OSD Menu | Multi-language |
| BLC Mode | BLC / HLC / DWDR |
| WDR | DWDR |
| Gain Control | AGC |
| Noise Reduction | 2D |
| White Balance | Auto / Manual |
| Smart IR | Auto / Manual |
| Certifications | |
| Certifications | CE (EN55032, EN55024, EN50130-4)FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
| Interface | |
| Audio Interface | N/A |
| Eelectrical | |
| Power Supply | 12V DC ±25% |
| Power Consumption | Max 2.8W (12V DC, IR on) |
| Environmental | |
| Operating Conditions | -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH* Start up should be done at above -40°C (-40°F) |
| Storage Conditions | -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH |
| Ingress Protection &Vandal Resistance | IP67 |
| Construction | |
| Casing | Plastic |
| Dimensions | 154.3mm×69.8mm×69.8mm (6.07″×2.75″×2.75″) |
| Net Weight | 0.20kg (0.44lb) |
| Gross Weight | 0.27kg (0.60lb) |
