System

• Main Processor Quad-core embedded processor
• Operating System Embedded LINUX

Display

•  Interface 1 HDMI, 1 VGA
• Resolution 3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768
• Multi-screen Display 1/4/8/9/16
• OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording

Video Detection and Alarm

• Trigger Events Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips
• Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Tampering
• Alarm input 16 Channel, Low Level Effective,
• Green Terminal Interface
• Relay Output 4 Channel, NO/NC Programmable,
• Green Terminal Interface
• Playback and Backup
• Playback 1/4/8/16
• Search Mode Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
• Playback Function Play, Pause, Stop, Rewind, Fast play, Slow Play,Next File, Previous File, Next Camera,Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
• Backup Mode USB Device/Network

Storage

• Internal HDD 4 SATA III Port, Up to 6 TB capacity for each HDD
• HDD Mode Single

Auxiliary Interface

• USB 2 USB Ports (1 USB2.0, 1 USB3.0)
• RS232 1 Port, for PC Communication and Keyboard
• RS485 1 Port, for PTZ Control
• Third-party Support Dahua, Arecont Vision, AXIS, Bosch, Brickcom,Canon, CP Plus, Dynacolor, Honeywell, Panasonic,

Audio and Video IP Camera

• Input 16/32 Channel
• Two-way Talk 1 Channel Input, 1 Channel Output, RCA
• Recording Compression H.265/H.264
• Resolution 8Mp/ 6Mp/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc.
• Record Rate 200Mbps
• Bit Rate 16Kbps ~ 20Mbps Per Channel
• Record Mode Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop
• Record Interval 1 ~ 120 min (default: 60 min), Pre-record:
• 1 ~ 30 sec, Post-record: 10 ~ 300 sec

Network

• Interface 2 RJ-45 Ports(10/100/1000Mbps)
• Ethernet Port 2 Ethernet Ports Joint Working or 2 Independent
• 1000Mbps Ethernet Port
• Network Function HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DNS, IP Filter, PPPoE,DDNS, FTP,
• IP Search (Support Dahua IP camera, DVR, NVS, etc.), Easy4ip

Max. User

• Access 128 users
• Smart Phone iPhone, iPad, Android
• Interoperability ONVIF 2.4, CGI Conformant

Electrical

• Power Supply AC100V ~ 240V, 50 ~ 60 Hz
• Power Consumption <11.7W (Without HDD)

Dimensions

• 1.5U, 440mm×411.1mm×76mm, (17.3″ x 16.2″ x 3.0″)
• Net Weight 4.5kg (9.9 lb) (without HDD)
• Gross Weight 7kg(15.4 lb)(without HDD)
