HDCVI DVR DH-HCVR-4116HS-S3

৳ 15,600.00 ৳ 11,700.00

DAHUA HD DVR 16 Channel | TRIBIRD HDCVI DVR (1080P) |Support HDCVI/ Analog & IP Camera

Category: Tag:

Description

Dahua HDCVI DVR DH-HCVR-4116HS-S3 Features

Dahua HDCVI DVR DH-HCVR-4116HS-S3 Support HDCVI/Analog/IP Video input
>H.264 dual-stream video compression
>HCVR4104/4108/4116HS-S3: All channel 1080N/720P recording
>HDMI/VGA simultaneous video output
>4/8/16 channel synchronous playback, GRID interface & smart search
>Support Multi-brand network cameras: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videosec, Vivotek and etc.
>ONVIF Version 2.4.1 conformance
>Support 1 SATA HDD up to 6TB, 2 USB2.0
>3D intelligent positioning with Dahua PTZ dome camera
>Multiple network monitoring: Web viewer, CMS(DSS/Smart PSS)&Smart Phone(DMSS)

Dahua HDCVI DVR DH-HCVR-4116HS-S3 Specifications

Model DH-HCVR-4116HS-S3  Dahua HD DVR
System
Main Processor Embedded processor
Operating System Embedded LINUX
Video
Input 16 channel, BNC
Standard Analog NTSC/PAL
HDCVI 1080P/720P HDCVI Camera
IP 4+1 up to 2Mp
Audio
Input 1 channel, RCA
Output 1 channel, RCA
Two-way Talk Reuse audio input/output channel 1
Display
Interface 1 HDMI, 1 VGA
Resolution 1920×1080, 1280×1024, 1280×720, 1024×768
Display Split 1/4/6 1/4/8/9
Privacy Masking 4 rectangular zones (each camera)
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Video/Audio Compression H.264/G.711
Resolution 1080N(960*1080)/720P(1280×720)/960H(960×576/960480)/ D1(704×576/704×480)/HD1(352×576/352×480) /BCIF(704×
Record Rate Main Stream: 1080N/720P/960H/D1/HD1/BCI F/CIF/QCIF(1~25/30fps) 1*1080N/720P(1~25/30fps)+ 7*(1~12/15fps)/960H/D1/HD1/BCIF/ CIF/QCIF (1~25/30fps)
Extra Stream CIF/QCIF(1~15fps) CIF/QCIF(1~7fps)
Bit Rate 1~4096Kb/s
Record Mode Manual, Schedule(Regular(Continuous),MD), Stop
Record Interval 1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection
Trigger Events Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips
Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Playback & Backup
Sync Playback 1/4 1/4/9
Search Mode Time/Date, MD & Exact search (accurate to second)
Playback Functions Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode USB Device/Internal SATA burner/Network
Network
Ethernet RJ-45 port (10/100M)
Network Functions HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P
Max. User Access 128 users
Smart Phone iPhone, iPad, Android, Windows Phone
Storage
Internal HDD 1 SATA port, up to 6TB
Auxiliary Interface
USB Interface 2 ports(1 Rear), USB2.0
RS485 1 port, For PTZ Control
General
Power Supply DC12V/2A
Power Consumption 10W(without HDD)
Working Environment -10°C ~+55°C / 10%~90%RH / 86~106kpa
Dimension(W×D×H) Compact 1U, 260mm×220mm×40mm
Weight 0.75KG(without HDD)

Download Datasheet

Dahua HDCVI DVR Video Demo
