Sale!

DHI-XVR-4108HS | Dahua 8 Channel PENTA BRID HD DVR

৳ 9,700.00 ৳ 8,200.00

SUPPORT HDCVI/CVBS/HDTVI/AHD

Category:

Description

DHI-XVR-4108HS – 8 Channel Penta-brid HD Digital Video Recorder

DHI-XVR-4108HS Support HDCVI/CVBS/HDTVI/AHD video inputs
>Max 5/10/18 channels IP camera inputs,each channel up to 5MP(2MP for 4ch)
>Max 20/40/72Mbps Incoming Bandwidth
>Long transmission distance over coax cable
>Support 1 SATA HDD, up to 6TB >Embedded processor



DHI-XVR-4108HS Specifications

System
Main Processor Embedded Processor
Operating System Embedded LINUX
Display
Interface 1 HDMI ,1 VGA
Resolution 1920×1080, 1280×1024, 1280×720, 1024×768
Multi-screen Display 4CH: 1/4/6

8CH: 1/4/8/9/16

16CH: 1/4/8/9/16/25

OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Video Detection and Alarm
Trigger Events Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video Detection Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering
Alarm input N/A
Relay Output N/A
Tracking Trigger Event N/A
Playback and Backup
Playback 4CH: 1/4

8CH: 1/4/9

16CH: 1/4/9/16

Search Mode Time /Date, Alarm, MD and Exact Search (accurate to second)
Playback Function Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup Mode USB Device/Network
Storage
Internal HDD 1 SATA Port, up to 6TB capacity
HDD Mode Single
eSATA N/A
Auxiliary Interface
Front Cover N/A
USB 2 USB Ports (2 USB 2.0)
RS232 N/A
RS485 1 Port, for PTZ Control
Third-party Support
Third-party Support Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
Audio and Video
HDCVI Camera Input 4/8/16 Channel
IP Camera Input 4+1: each channel up to 2MP

8+2/16+2:each channel up to 5MP

Audio In/Out 1/1
Two-way Talk Reuse audio in/out, RCA
Recording
Compression H.264
Resolution 1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF
Record Rate Main Stream:

4CH:1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps)

8/16CH:1080N(12fps)/720P(15fps)/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps)

Sub steram:D1/CIF/QCIF(1~25/30fps)

Bit Rate 1Kbps ~ 6144Kbps Per Channel
Record Mode Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Record Interval 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Network
Interface 1 RJ-45 Port (100M)
Network Function HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server,P2P, IP Search (Support Dahua IP camera, DVR, NVS, etc.)
Max. User Access 128 users
Smart Phone iPhone, iPad, Android
Interoperability ONVIF 2.4.1, CGI Conformant
Electrical
Power Supply DC12V/2A
Power Consumption <10W (Without HDD)
Environmental
Operating Conditions -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa
Storage Conditions 0°C ~ +50°C (+32°F ~ +122°F), 0 ~ 90% RH
Construction
Dimensions Compact 1U, 260×236×48mm(10.2″×9.3″×1.9″)
Net Weight 0.75kg ( 1.7lb) (without HDD)
Gross Weight 1.5kg (3.3lb)
Installation Desktop installation
Certifications
Certifications FCC: Coming soon
UL: Coming soon

Download DHI-XVR-4108HS Datasheet

Best Compatible Camera   | Free iPhone and Android Wise View App



Customer Questions & Answers

Question: Does this dvr work with other camera brands?

Answer: Yes, this HD DVR support analog cc camera , ip camera and also Avtech, Hikvision, Cp plus  Brand Camera.

Question: IS this DVR shows a clear picture?

Answer: This DVR shows a very clear picture from any cameras. It is highly recommend for any HD CAMERA.

Question:  What about Warranty & Support?

Answer: Yes, Of course – 1 Year Warranty and support available.

Question: Does it come with Hard Disk?

Answer:  No, You have to purchase separately.
