-10%
DHI-XVR-5108C
Original price was: ৳ 10,000.00.৳ 8,000.00Current price is: ৳ 8,000.00.
NVR 4432-4K | 32 Channel Dahua 4K NVR
Original price was: ৳ 37,000.00.৳ 34,000.00Current price is: ৳ 34,000.00.
DH-XVR4232AN
Original price was: ৳ 21,000.00.৳ 19,000.00Current price is: ৳ 19,000.00.
DAHUA HD DVR 32 Channel | TRIBIRD HDCVI DVR (1080P) |Support HDCVI/ Analog & IP Camera
Call For Wholesale Best Price 01611605422 (WhatsApp)
DH-HCVR4232AN 32 Channel Tribrid Digital Video Recorder
>Embedded processor
>Support HDCVI/CVBS video inputs
>Max 16 channels IP camera inputs
>Max 64Mbps Incoming Bandwidth
>Long transmission distance over coax cable
>Support 2 SATA HDD, up to 12TB
>Support HDCVI/CVBS video inputs
>Max 16 channels IP camera inputs
>Max 64Mbps Incoming Bandwidth
>Long transmission distance over coax cable
>Support 2 SATA HDD, up to 12TB
DH-HCVR4232AN Specifications
| System | |
| Main Processor | Embedded Processor |
| Operating System | Embedded LINUX |
| Display | |
| Interface | 1 HDMI ,1 VGA,1 TV |
| Resolution | 1920×1080, 1280×1024, 1280×720, 1024×768 |
| Multi-screen Display | 1/4/8/9/16/25 |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Video Detection and Alarm | |
| Trigger Events | Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering |
| Alarm input | — |
| Relay Output | — |
| Tracking Trigger Event | — |
| Playback and Backup | |
| Playback | 1/4/9/16 |
| Search Mode | Time /Date, Alarm, MD and Exact Search (accurate to second) |
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode | USB Device/Network |
| Storage | |
| Internal HDD | 2 SATA Ports, up to 6TB capacity for each disk |
| HDD Mode | Single |
| eSATA | — |
| Auxiliary Interface | |
| USB | 2 USB Ports (1 USB 3.0,1 USB 2.0) |
| RS232 | — |
| RS485 | 1 Port, for PTZ Control |
| Third-party Support | |
| Third-party Support | Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
| Audio and Video | |
| HDCVI Camera Input | 32 Channel |
| IP Camera Input | 16 Channel, each channel up to 5MP |
| Audio In/Out | 1/1 |
| Two-way Talk | Reuse audio in/out, RCA |
| Recording | |
| Compression | H.264 |
| Resolution | 1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF |
| Record Rate | Main Stream: 1080N(12fps)/720P(15fps)/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps)
Sub steram:D1/CIF/QCIF(1~25/30fps) |
| Bit Rate | 1Kbps ~ 6144Kbps Per Channel |
| Record Mode | Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Record Interval | 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
| Network | |
| Interface | 1 RJ-45 Port (1000M) |
| Network Function | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server,P2P, IP Search (Support Dahua IP camera, DVR, NVS, etc.) |
| Max. User Access | 128 users |
| Smart Phone | iPhone, iPad, Android |
| Interoperability | ONVIF 2.4.1, CGI Conformant |
| Electrical | |
| Power Supply | DC12V/5A |
| Power Consumption | <20W (Without HDD) |
| Environmental | |
| Operating Conditions | -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa |
| Storage Conditions | 0°C ~ +50°C (+32°F ~ +122°F), 0 ~ 90% RH |
| Construction | |
| Dimensions | 1U, 375mm×285mm×55mm (14.8″ x 11.2″ x 2.2″) |
| Net Weight | 2.35kg (5.2 lb) (without HDD) |
| Gross Weight | 3.2kg (7.05lb) |
| Installation | Desktop installation |
| Certifications | |
| Certifications | FCC: Part 15 Subpart B ICES 003 Issue 6 |
| CE: EN 55032: 2012+AC:2013 (Class B)
EN 55024 : 2010 EN 61000-3-2 : 2014 EN 50130-4: 2011 EN 61000-3-3 : 2013 |
|
| UL 60950-1 and CAN/CSA C22.2 No. 60950-1-07 | |
Dahua Network Video Recorder
