Dahua Technology Takes HDCVI 4K now is available over COAX

Dahua Technology Takes HDCVI 4K now is available over COAX

HANGZHOU, China / April 28, 2017 HD analog is quickly becoming the mainstream of analog video. By 2018, over 90% of analog cameras will be HD analog (according to 2016 IHS report). Dahua led the industry to introduce HDCVI Technology in 2012, and continues to enhance the technology leadership by bringing state of the art performance in terms of resolution, light sensitivity, intelligence and usability to the HDCVI community. The comprehensive offering of HDCVI matches up very well to the IP equivalent. Customers can choose the most suitable system for their sites without being constrained to IP only. The emergence of multi-mode DVR, which records video from HDCVI, TVI, AHD, CVBS and IP cameras, makes it very easy to upgrade a site by increment.

Future development of HD analog must fit the needs of IoT and big data applications, which is driving the value of security systems in the next few years. AI (Artificial Intelligence) Deep Learning will be a key technology component to enable this to happen.

Enter a New Era – HDCVI 4.0

Dahua is introducing HDCVI 4.0 technology framework, with 3 key components: 4K-HDCVI for superior video capture, IoT-HDCVI for multi-dimensional sensing and AI-HDCVI to transform HDCVI-video into searchable Boolean data. New products will be introduced throughout the year in 2017 to enhance the user experience of HDCVI customers. The HDCVI community can expect a lot more opportunities to use HDCVI technology to expand security application space.

Dahua 4K-HDCVI adopts 4K Ultra HD image acquisition and back-end DVR storage. HDCVI technology architecture overcame the common bottleneck of transmission bandwidth to achieve high resolution video previously only available on IPC. This is a major breakthrough to extend the potential of HDCVI in future. Dahua IoT-HDCVI technology, combining with IoT sensing technology, enables cameras to surpass basic function of providing video information. Utilizing IoT sensors, coaxial cables are capable of transmitting not only video signal, but also information such as alarm, temperature and humidity. HDCVI technology architecture supports complex data transmission between camera and DVR, and makes it possible for multi-dimensional sensing camera and DVR to form an IoT solution. The near real-time transmission of HDCVI also improves the responsiveness of IoT applications. Dahua AI-HDCVI technology integrates HDCVI video and audio with AI (Artificial Intelligence) Deep Learning. AI-HDCVI performs near-human level accuracy in image classification and voice recognition to transform HDCVI video and audio into searchable Boolean data. The output of these analysis could solve resource allocation problems for example, in the retail industry with customer and or in the management of city transportation with vehicle traffic analysis.

The scalable and expandable architecture of HDCVI enables future-proof products and solutions to be developed. It protects customers’ investment by allowing seamless upgrade to new technologies as they emerge. Dahua HDCVI 4.0 comprises of 4K-HDCVI, IoT-HDCVI and AI-HDCVI leads the industry into a new era of higher resolution, more intelligent and convenient.

Dahua Technology Brings HDCVI into the 4K Era, a Brighter World

4K-HDCVI is the first product launched by Dahua Technology in 2017. While the industry is trying to break through the bandwidth constraint of coaxial cable transmission, Dahua releases the first 4K Ultra HD solution by deploying superior signal modulation mechanism and noise reduction technique. It transmits 4K video signal up to 700m (RG6 cable). Dahua 4K-HDCVI offering includes 4K box camera, 4K IR bullet& dome camera, 4K fish-eye panoramic camera, 4K multi-sensor 180 degree panoramic camera, and a series of 4K supported XVR (multi-mode DVR). Dahua4K-HDCVI offering delivers 3840(H) x 2160(V) ultra-high resolution images, equivalent to 4X 1080 HD camera’s, to achieve wide angle coverage and clear video evidence at the same time.

All HD analog technologies, limited by the data transmission capacity of coaxial cables, were not able to provide 4K resolution. Dahua Technology, leveraging on our superior signal modulation mechanism and noise reduction technique, developed TX &RX chipsets autonomously to break through this limitation. Dahua 4K-HDCVI products are capable of ultra-distance transmission:

● RG6 coaxial cables for 700m video and audio lose-less transmission
● RG59 coaxial cables for 500m video and audio lose-less transmission
● UTP Cat 6 network cable for 300m video and audio lose-less transmission


The New 4K XVR recorder is compatible with all existing HDCVI/HDTVI/AHD cameras, meanwhile, it also supports CVBS and IP cameras. All these make upgrading to 4K much more convenient and cost-effective. The installation, configuration, operation and maintenance of 4K HDCVI are the same as before, preserving the plug & play convenience of analog video system. Once your existing DVR is replaced by a new 4K XVR, you can simply replace the existing camera with 4K camera or add 4K camera as you go.
DH-HAC-HF3805G, adopts the SONY 4/3” 8MP STARVIS sensor, is able to output 3840(H) x2160(V) ultra HD images with impressive night performance due to the bigger size sensor. It is also the first HD analog camera to utilize M43 mount lens in the security industry which brings the rich selection of M43 lenses to customers. Users can choose their preferred lens based on different scenarios. This camera also delivers functions like autofocus, image magnification for dynamic detection and a linkage alarm without the need to use with the back-end. All the settings and functions can be easily controlled by the OSD menu, and use together with applicable housing, this camera is good for outdoor surveillance. DH-HAC-HF3805G is truly THE camera for high performance surveillance under poor illumination.
